Aventon Abound LR Ebike

$1,299.00

Carry More, Ride More

Size: One Size 4'11” - 6'2”

Color

Clear

SKU: N/A Categories: Cargo Bike, Step-Through Brand: Abound Ebikes, Aventon

Description

Abound LR Ebike

The Abound LR is the perfect solution for all your cargo needs! With a powerful 750W motor, extended rear rack, and a 440lb payload capacity, it’s built to handle anything. Whether it’s the kids, beach gear, or an epic grocery haul, the Abound LR has you covered. Its gravity cast frame, adjustable quill stem, front suspension, and suspension seatpost ensure a smooth and comfortable ride no matter the load. Plus, with ACU technology, you can easily track and manage your bike from anywhere. The possibilities are endless—load up and hit the road with the Abound LR!

Cruise Control

Cruise Control lets you lock in your perfect pace with the push of a button. Whether you’re riding down country roads or open trails, it keeps your speed steady so you can focus on the ride—not the pedals.

Sensor Switch

Like two bikes in one, choose between using a Torque or Cadence sensor with Sensor Switch. Whether you want to feel the power on the pedals or just cruise, Aventon’s Sensor Switch gives you the option to optimize your ride.

Integrated Kickstand Lock

The kickstand lock keeps the bike securely parked by preventing it from being moved or rolled away while the kickstand is down—ideal for securely loading your cargo or passengers and for quick stops during your daily adventures.

Boost Mode

Available on all ACU-equipped, hub-driven ebike models, Boost Mode allows the rider to access up to 120% of specced torque and peak power for up to 30 seconds at a time. It turns steep hills into shortcuts and handles heavy hauls hassle-free.

Ride Tune

The ride tune feature lets you customize torque, assistance, and pedal response in each assist mode, making it easier to start smoothly with heavy loads, maintain control with passengers on the back, and ride more efficiently with varying amounts of cargo.

Hold Mode

Keep gravity at bay when you need a break. Hold Mode keeps your bike from rolling backwards when you need a break from walking it up an incline. Release the Walk Mode button to activate Hold Mode for up to 30 seconds at a time.

Startup Password

The optional startup password adds customizable security by allowing you to set a personal code on the bike’s display, helping to prevent unauthorized use of your bike.

Cross-Model Keyless Battery System

Quickly unlock and remove your battery directly through the bike’s display, offering fast, secure, and convenient access without worrying about keeping track of a set of keys. With cross-model compatibility, your Abound LR battery will also work on the Abound SR, Aventure 3, Level 3, and Pace 4.

Over-the-Air Updates

Over-the-air updates ensure your bike receives the latest ride features and improvements automatically through the bike’s display, keeping it up to date without a visit to the shop.

Technical Specifications

General Info
Model	Abound LR Ebike
Weight	88 lbs
Total Weight Limit	440 lbs
Rider Height	4'11" - 6'3"
Ebike Class	Class 2 Ebike
Range	Up to 60 miles
Battery Safety Certifications	Certified to UL 2271
Safety Certifications	UL and TUV Safety Certified  UL 2849
Ideal Use	Cargo & Utility
Pedal Assist	3 Levels (with Ride Tune Customization)
Carry Capacity	Carry Up To 2 Passengers
Water Resistance	Bike - IPX5 // Components - IPX6
Frameset
Frame	Gravity Cast 6061 Single-Butted Aluminum Alloy with Internal Battery
Fork	Threaded Steerer Tube for Quill Stem 15x110 spacing, 51mm travel, adjustable lockout, black stanchions
Rear Spacing	175mm
Fork Spacing	110mm
Frame Style	Step-Through
Wheelset
Front Wheel	Double Wall Aluminum, 20in, 36hole, 13g, 20x110 Thru Axle, Schrader Valve
Rear Wheel	Double Wall Aluminum, 20in, 36hole, 12g, Nutted Hub Drive Motor, Schrader Valve
Tires	20 x 3.0 Innova IA-2131 Urban Tire, Reflective Sidewalls
Ebike System
Motor	Shengyi 36V 750w Hub Drive with 6 speed sensors (1188W peak)
Motor Torque	80Nm
Display	Aventon BC147
Battery	Removable Internal Lithium-ion, 36V, 20Ah, 733Wh, LG 21700 cells
Battery Weight	8.7 lbs
Controller	36V/33A
Throttle	Aventon LH Handlebar Mounted
Sensors	Double Sided Bottom Bracket Torque Sensor
Charger	36V Output: 42V/4A
Charging Time (0–100%)	5 hours
Lights	Front and Rear Lights Integrated with Turn Signals
Speed	Class 2
Brakes
Front Brake	Tektro HD-E3520 hydraulic disc brakes w/ EJ1 quick disconnect wire
Rear Brake	Tektro HD-E3520 hydraulic disc brakes w/ EJ1 quick disconnect wire
Front Brake Rotor	180mm 6 bolt
Rear Brake Rotor	203mm 6 bolt
Drivetrain
Rear Derailleur	Shimano Altus RD-M310 8 Speed
Shifter	Shimano 8 Speed Trigger SL-M315-8R
Chain	7/8 speed 154L
Cassette	12-32T / 8 Speed Shimano CS-HG200-8
Chainring	52 tooth
Crank	3pc, 165mm crank arm
Bottom Bracket	Square Taper, Sealed, Dual-Sided Torque Sensor
Pedals	9/16" Composite Platform
Cockpit
Saddle	Aventon Saddle w/ grab handle by Selle Royal
Seatpost	Aventon Suspension Seatpost, Ø 30.9mm, 350mm Length, 50mm travel
Seatpost Clamp	34.9mm
Handlebars	BMX Style Aluminum, 31.8mm, 720mm
Grips	Aventon Ergonomic Comfort Lock-on Grips
Headset	H886HW Peilin 28.6mm × 56mm × 56mm H19.5mm, 6pcs
Included Accessories
Fenders	Included
Rear Rack	Included
Rear Rack Weight Limit	143 lbs

Technical Overview

The Abound LR is a Class II e-bike equipped with both pedal assist and throttle capabilities. It can also function with the throttle unplugged and removed, making it suitable for areas permitting only Class I e-bikes or where throttles are restricted. Aventon e-bikes are manufactured to meet the IPX5-rated standard, offering protection against low-pressure water jets from any direction. This ensures moderate water resistance, allowing use in light to moderate rain or small puddles. However, an IPX5 rating does not mean the bike is waterproof; Aventon e-bikes are not designed for full submersion. Avoid using high-pressure sprayers or pressure washers when cleaning, as pressurized water can damage components. *Maximum range is calculated using PAS 1 on flat terrain with a rider weight of 160 lbs.*

Geometry

Abound LR Ebike is available in 1 sizes to suit most adults.

One Size Fits Most
A - Seat Tube Length	380mm (15")
B - Top Tube Length Horizontal	610mm (24")
C - Bottom Bracket Drop	30mm (1")
D - Head Tube Length	210mm (8")
E - Head Tube Angle	69°
F - Seat Tube Angle	70°
G - Rear Chainstay Length	660mm (26")
H - Front Wheel Center	673mm (26")
I - Wheelbase	1332mm (52")
J - Reach	420mm (16")
K - Stack Height	521mm (20")
L - Fork Length	394.5mm (15")
M - Fork Offset	38mm (1")
N - Trail	63mm (2")
Wheel Size in Inches	20"
Rider Height (Range)	150cm - 198cm (4'11"-6'3")
